型号：ZQ-TP10-YL

主炉尺寸：φ 2000*7700

医疗垃圾处理量/炉：5~8吨

工作压力：常压

工作温度：-20~400℃

占地面积：2辆17.5M板车

总功率：30KW

Model: ZQ-TP10-CZ

Main furnace size: φ 2000*7700

Medical waste treatment capacity / furnace: 5~8 tons

Working pressure: normal pressure

Working temperature: -20~400 ℃

Floor area: 60m*50m

Total power: 30kw

配置单:前置出渣器、热解主炉、主炉炉膛、加热系统（包含重油燃烧枪*2、废气燃烧枪*4、风机*1、加热系统供给油罐）、分汽包、废气燃烧室、喷淋塔*2、隔流沉淀池、风机、水箱式冷凝器、中转储油罐*2、水封、脱水罐、溢出罐、配电柜小阻尼罐*3、循环水池、冷却塔、循环水泵、齿轮油泵等。

Allocation list: front slag outlet, pyrolysis main furnace, main furnace base, heating system (including heavy oil combustion gun * 2, exhaust gas combustion gun * 4, fan * 1, heating system supply oil tank), steam drum, exhaust gas combustion chamber, spray tower * 2, flow isolation sedimentation tank, fan, water tank condenser, transfer oil storage tank * 2, water seal, dehydration tank, overflow tank, distribution cabinet small damping tank * 3, circulating pool, cooling tower, circulating water pump, gear oil pump, etc.
